It has been in operation since January 2010 for the purpose of providing more appropriate information to consumers in an easy-to-understand manner. Based on the grading system (grading system), it is a system established as an industry voluntary standard to classify "rolling resistance performance" and "wet grip performance" and label them.
Unit(N/kN)
(RRC) | Grade |
RRC≦6.5 | AAA |
6.6≦RRC≦7.7 | AA |
7.8≦RRC≦9.0 | A |
9.1≦RRC≦10.5 | B |
10.6≦RRC≦12.0 | C |
Unit(-)
Wet Grip performance (G) |
Grade |
155≦G | a |
140≦G≦154 | b |
125≦G≦139 | c |
110≦G≦124 | d |
Note:
Tyres with a rolling resistance coefficient above 12.0, or wet grip performance tyre under 110 (in comparison with SRTT) is exempted from the scope of this system.
The tyres with a grading of A and above for rolling resistance performance and grading a to d for wet grip performance are defined as "Fuel Efficient Tyres", and uniform mark (right) is marked to promote use.
Example
■ Fuel Efficient Tyre
Tyres with this label has a AA grade for rolling resistance performance and c grade for wet grip performance, and means that this tyre is a fuel efficient tyre.
■ Non Fuel Efficient Tyre
Tyres with this label has a B grade for rolling resistance performance and b grade for wet grip performance.
…Rolling Resistance Performance
…Wet Grip Performance
...Fuel Effcient Tyre
Note:
This label may be marked on information providing media (example: tyre label, catalogue, website, etc.) of tyres that have conformed with the Labeling System of Japan Automobile Tyre Manufacturers Association Inc., (Guideline for tyre labeling to promote the use of fuel efficient tyres; December 4, 2009) and its evidence data is reported to the Tire Fair Trade Council.
Note:
May be punished by law etc., in case the label is non-conformity (false) with this labeling system, or if it is confirmed that the label is unjustly used.
By reducing the rolling resistance of tyres, fuel efficiency is improved and CO2 emissions of automobiles can be reduced.
JATMA is calculating the CO2 emission reductions by using the rolling resistance data of our member companies(full members).
※For details, please refer to "Effect of Decreasing Rolling Resistance in Passenger-vehicle Tyres in Reducing CO2 Emissions".
Currently, the following 14 companies are participating the labeling system.
General Affairs Department
No.33 Mori Bldg. 8Floor 3-8-21 Toranomon, Minatoku, Tokyo, JAPAN 105-0001
TEL.+81-3-3435-9095 FAX.+81-3-3435-9097
E-mail labeling#system=jatma.or.jp
(Please change"#"to"-"(hyphen)and "="to"@"when you send us an email.)
* This e-mail address is for inquiry about the relevant system only. We are sorry but we are unable to answer other inquiry or messages.
The Tire Fair Trade Council operates the "Fair Competition Code for Tyre Labeling" and the "Fair Competition Code Enforcement Regulations". Based on this, the business operator conducts a test based on the standards such as the test method for comparative display, and then, when displaying for consumers based on the test results, the test is conducted in advance. Data will be submitted to the Tire Fair Trade Council.
